hostname R1
ipv6 unicast-routing
# Step 1: Configure a Named EIGRP virtual instance
router eigrp TEST
# Step 2: Specify an address family along with its autonomous system number
address-family ipv4 unicast autonomous-system 1
# Step 3: Configure general EIGRP settings (network, eigrp router-id, eigrp stub, metric)
network 10.1.1.0 0.0.0.3
network 172.16.1.0 0.0.0.255
eigrp router-id 1.1.1.1
# Step 4: Enter Address-Family-Interface mode (default | interface-id) to apply changes to interfaces (authentication, bandwidthpercent, hello-interval, hold-time, passive-interface, split-horizon)
af-interface default
hello-interval 2
hold-time 10
passive-interface
af-interface Serial1/0
no passive-interface
# Step 5: Enter Address-Family-Topology mode and configure the topology (autosummary, maximum-paths, redistribute, variance)
topology base
variance 2
address-family ipv6 unicast autonomous-system 2
af-interface default
hello-interval 2
hold-time 10
passive-interface
af-interface Serial1/0
no passive-interface
topology base
variance 2
hostname R2
ipv6 unicast-routing
router eigrp TEST
address-family ipv4 unicast autonomous-system 1
network 10.1.1.0 0.0.0.3
network 192.168.1.0 0.0.0.255
eigrp router-id 2.2.2.2
af-interface default
hello-interval 2
hold-time 10
passive-interface
af-interface Serial1/0
no passive-interface
topology base
variance 2
address-family ipv6 unicast autonomous-system 2
af-interface default
hello-interval 2
hold-time 10
passive-interface
af-interface Serial1/0
no passive-interface
topology base
variance 2
R1#show ip protocols
Routing Protocol is "eigrp 4"
Outgoing update filter list for all interfaces is not set
Incoming update filter list for all interfaces is not set
Default networks flagged in outgoing updates
Default networks accepted from incoming updates
EIGRP-IPv4 VR(TEST) Address-Family Protocol for AS(4)
Metric weight K1=1, K2=0, K3=1, K4=0, K5=0 K6=0
Metric rib-scale 128
Metric version 64bit
NSF-aware route hold timer is 240
Router-ID: 1.1.1.1
Topology : 0 (base)
Active Timer: 3 min
Distance: internal 90 external 170
Maximum path: 4
Maximum hopcount 100
Maximum metric variance 2
Total Prefix Count: 3
Total Redist Count: 0
Automatic Summarization: disabled
Maximum path: 4
Routing for Networks:
10.1.1.0/30
172.16.1.0/24
Passive Interface(s):
FastEthernet0/0
Routing Information Sources:
Gateway Distance Last Update
10.1.1.2 90 00:22:30
Distance: internal 90 external 170
R1#show ipv6 protocols
IPv6 Routing Protocol is "connected"
IPv6 Routing Protocol is "ND"
IPv6 Routing Protocol is "eigrp 2"
EIGRP-IPv6 VR(TEST) Address-Family Protocol for AS(2)
Metric weight K1=1, K2=0, K3=1, K4=0, K5=0 K6=0
Metric rib-scale 128
Metric version 64bit
NSF-aware route hold timer is 240
Router-ID: 172.16.1.1
Topology : 0 (base)
Active Timer: 3 min
Distance: internal 90 external 170
Maximum path: 16
Maximum hopcount 100
Maximum metric variance 2
Total Prefix Count: 3
Total Redist Count: 0
Interfaces:
Serial1/0
FastEthernet0/0 (passive)
Redistribution:
None
